ASI QUINT 100-240/2.4 EFD
Technical Data
Input Data
Nominal input voltage (wide-range input)
Input voltage range
Frequency
Current consumption (for nominal values)
Inrush current limiting/I 2 t (+25°C [+77°F])
Mains buffering for a nominal load (typical)
Switch-on time after applying the mains voltage
Transient surge protection
Input fuse, internal (device protection)
Recommended backup fuse
Circuit breaker
Characteristic (EN 60898)
Discharge current for PE
Output Data
Nominal output voltage U N /tolerance
Output current during convection cooling:
100 V AC - 240 V AC
85 V AC - 264 V AC/90 V AC - 350 V DC
45 Hz - 65 Hz/0 Hz
1.2 A (120 V AC)/0.5 A (230 V AC), approximately
< 15 A/< 2.2 A 2 s, typical
> 20 ms (120 V AC)/> 80 ms (230 V AC)
< 0.5 s
Varistor
5 AT
6 A/10 A/16 A
B
< 3.5 mA
30.1 V DC/±1.5%
POWER BOOST I BOOST
-25°C to +40°C (-13°F to +104°F)
Nominal output current I N
-25°C to +60°C (-13°F to +140°F)
3A
2.4 A
(U out = 30.1 V DC)
(U out = 30.1 V DC)
Derating from +60°C (+140°F)
Short-circuit current limit I BOOST , approximately
Startup of unlimited capacitive loads
Maximum power dissipation No load/nominal load,
approximately
Efficiency (for 230 V AC and nominal values)
Residual ripple/switching peaks
(0 - 10 kHz/10 - 500 kHz)
Internal surge protection
Resistance to return supply
Signal Output Data
EFD (floating: ground fault detected = contact open)
EFD (ground fault detected = LED flashes)
LED DC OK (U out < 0.9 x U N = LED flashes)
2.5%/K
≈ 3A
Yes
3 W/11 W
> 86%
< 100 mV SS /< 50 mV SS
Yes, < 35 V DC
35 V DC
≤ 30 V AC/DC; ≤ 1 A
Red LED
Green LED
2
